| Display Type | 7 Segment LED Dual Display | |
| Display Configuration | 4+4 digits | |
| Type of Inputs | Thermocouple: J, K, T, R, S, C,E, B, N, L, U, W, Platinel II. RTD: PT100, Signal Inputs: (DC) -5 to 56mV, 0 to 10V, 0 to 20mA (Selectable) | |
| Control Output | Relay or SSR or Current : 0/4 to 20mA DC (max load 500E) or Voltage :0 to 5/10V DC(min load 10K) | |
| Auxiliary Output | Relay | |
| Feature | Extra alarm output, Retransmission output | |
| Communication |
|
|
| Supply Voltage |
|
|
| Size | 48mm x 48mm | |
| Mounting Type | Panel mount | |
| Certification |
|
| Display Type |
|
|
| Display Configuration | 4+4 digits | |
| Type of Input | Thermocouple: J, K, T, R, S, C, B, N, L, U, W, Platinel II RTD: pt100, Single Input (DC) -5 to 56mV, 0 to 10V, 0 to 20mA (Selectable) | |
| Control Output | Relay | |
| Auxiliary Output | Relay | |
| Feature | Extra alarm output , Retransmission output. | |
| Supply Voltage | 85 to 270V AC | |
| Size | 96mm x 48mm | |
| Mounting Type | Panel mount | |
| Certification | CE in process |
| Display Type | 7 Segment LED Dual Display |
| Display Configuration | 4+4 digits |
| Type of Input | Thermocouple: J, K, T, R, S, C, B, N, L, U, W, Platinel II RTD: pt100, Single Input (DC) -5 to 56mV, 0 to 10V, 0 to 20mA (Selectable) |
| Control Output | Relay or Current : 0/4 to 20mA DC (max load 500E) |
| Auxiliary Output | (Maximum 2)Relay ( Mode:Set Point or Alarm mode ) |
| Feature | Extra alarm output , Retransmission output |
| Supply Voltage | 85 to 270V AC |
| Size | 96mm x 96mm |
| Mounting Type | Panel mount |
| Certification | CE |
